當前位置：熱熔膠涂布機的涂布控制系統作用有哪些？
時間：2023-05-04 來源：http://www.yalais.com/ 發布人：昌盛機械
熱熔膠涂布機可將固態的熱熔膠熔化，并通過加壓裝置將熔化后變為液態的膠輸送到膠涂布裝置對基材實行涂布。集精確溫度控制功能﹑流體加壓輸送功能和擠出涂布功能于一體的機電設備。另具備自動控制及自動跟蹤生產線速度的功能。
The hot melt adhesive coating machine can melt the solid hot melt adhesive and transport the melted liquid adhesive to the adhesive coating device through a pressure device for coating the substrate. An electromechanical device that integrates precise temperature control, fluid pressure delivery, and extrusion coating functions. It also has the function of automatic control and automatic tracking of production line speed.
主機:具備加熱保溫,熔化膠液,輸出膠液,控制膠液壓力,初級過濾等功能.主機溫度應控制在比膠液熔點溫度高5-10度.使之具有一定的流動性.使壓力控制更為準確
Host: Equipped with functions such as heating and insulation, melting glue, outputting glue, controlling glue pressure, primary filtration, etc. The host temperature should be controlled at 5-10 degrees higher than the glue melting point temperature to ensure a certain degree of fluidity and more accurate pressure control
喉管:具備加熱保溫,導流膠液的作用,將液態熱熔膠由主機輸出至槍座模塊的功能.溫度保持在稍高于膠液熔點溫度即可。
Throat: It has the function of heating and insulation, guiding the glue liquid, and outputting the liquid hot melt glue from the host to the gun base module. The temperature should be maintained slightly above the glue melting point temperature.
槍座:具備加熱保溫,二級過濾.并將膠液輸送至槍體.并視需要,加熱壓縮空氣的功能.可視噴膠效果適當提高溫度。使膠液流動性更好。
Gun base: Equipped with heating and insulation, secondary filtration, and the function of conveying glue to the gun body. It can also heat compressed air as needed. The temperature can be appropriately increased according to the visual spraying effect. Improve the fluidity of the adhesive.
槍體:具備打開及關閉膠液的功能.并按需求配套各種噴嘴及刮嘴.以滿足用戶的需求.有螺旋噴槍，涂布刮槍，纖維噴槍，Z字型噴槍，點狀槍等等。
Gun body: It has the function of opening and closing glue, and is equipped with various nozzles and scrapers according to needs to meet user needs. There are spiral spray guns, coating scrapers, fiber spray guns, Z-shaped spray guns, point guns, and so on.
自動補償控制系統：具備輸出信號控制電磁閥，由電磁閥控制的壓縮空氣帶動槍體的工作來控制膠液的打開及關閉。并輸出0-10V 直流電壓控制變頻器帶動馬達轉動。輸出電壓與被被測生產線速度成正比。可在線調整膠位、斷膠長度及跟蹤電壓。檢測生產線速度的裝置有接近開關，旋轉編碼器等。
Automatic compensation control system: Equipped with output signal control solenoid valve, the compressed air controlled by the solenoid valve drives the operation of the gun body to control the opening and closing of the glue. And output 0-10V DC voltage to control the frequency converter to drive the motor to rotate. The output voltage is proportional to the speed of the tested production line. Can adjust the glue position, broken glue length, and tracking voltage online. Devices for detecting production line speed include proximity switches, rotary encoders, etc.
本文由中空玻璃丁基膠涂布機進行編寫，想要了解更多的產品及更詳細的精彩內容，請關注我們的網站:http://www.yalais.com我們將為您呈現更多的內容。
This article is written by the insulating glass butyl adhesive coating machine. If you want to learn more products and more detailed exciting content, please follow our website: http://www.yalais.com We will present more content for you.
